Compositor bridge

Use this socket API to build a dock, launcher or window switcher. It lets your shell read windows, request window actions and take temporary input grabs for interactive UI. Put persistent shortcuts in the Lua config. Your shell still draws the UI and decides how to group and order windows.

For terminal commands and scripts, gnoblinctl handles the connection for you.

Availability

The bridge is a built-in Gnoblin compositor service. It starts with the Gnoblin Shell component, stays available across gnoblinctl reload, and does not need to be installed under ~/.config/gnoblin/scripts/. gnoblinctl window list uses the same socket. Check gnoblinctl status before debugging a client connection.

Bingux is a separate shell project that uses this interface. A custom shell can connect to it without installing Bingux.

Bingux is one shell example built on Gnoblin's compositor interfaces.

Connect

Socket: $XDG_RUNTIME_DIR/gnoblin/compositor-v1.sock. Use GNOBLIN_COMPOSITOR_SOCKET on both ends for a private test path.

The server sends a greeting, including available features:

{ "event": "hello", "version": 1, "features": ["ui-sessions", "switcher-fallback", "overlay-shortcut"] }

Additional features depend on the running build. Send one UTF-8 JSON object per line, followed by a newline. Keep the connection open.

Read the socket protocol version from hello.version. Check features before using an optional capability:

• Bare Super requires overlay-shortcut.
• blur-region requires blur-regions.
• layer-animation-policy requires the same-named feature.

A validation error has an error event. If a valid command request fails, the response also carries its request id. Malformed JSON or excessive input closes the socket; ordinary validation errors leave it open.

Operation index

op	Required fields	Reply or stream
command	id, command; command-specific fields	One reply with matching id, or error
windows	None	Current windows snapshot, then changes
privacy	None	Current privacy state, then changes
status	None	One status with binding IDs and active session ID
bind	id, accelerator, hold; optional trigger, modal, captureInput	bound, then activation and input events
activate	window; optional session for the built-in switcher fallback	Focus a window; no success reply
preview	window, width, height	One preview event
shortcut-input	name, state	Input handoff; no success reply
ui-session	action; other fields depend on action	ui-state or ui-command events
layer-animation-policy	namespace	One policy event for that layer namespace
blur-region	namespace, screen, region	No success reply
window-drag	None	Current window-drag state, then changes
snap-offer	serial, regions	No success reply; may later get snap-completed
snap-context	None	One snap-context event
snap-window	window, monitor, target	Applies a region; no success reply
stop-sharing, stop-recording	None	Requests stop; no success reply
end	Optional session for fallback switcher	Ends this client's input session
clear	None	Removes this client's bindings and session

When a client claims a built-in switcher shortcut, pass the matching session from its activated event with activate. Gnoblin ignores an activation from an older switcher session.

command supports these operations:

• Window records: windows, capture-windows.
• Workspaces: workspaces, workspace-list, workspace-switch, workspace-next, workspace-previous, workspace-move-active.
• monitors lists monitors; layers returns layer-shell surfaces.
• window takes an action and a stable window ID or "active".
• animation lists, inspects and previews registered animations. See the animation CLI guide.

Successful command requests return an event: "reply" with the matching ID and a result object. Read-only results use these shapes:

Command	Result field	Contents
windows	windows[]	The same fields as gnoblinctl window list --json.
capture-windows	windows[]	id, title, appId, appName, frame x, y, width, height, and bufferWidth, bufferHeight.
monitors	monitors[]	id, x, y, width, height, primary, and scale; see monitor records.
layers	surfaces[]	Layer-shell id, namespace, and title; see layer surfaces.

The CLI reference lists window actions and arguments.

Workspace commands

Use workspace-list to get the workspace ID, current one-based number, display name, active state and eligible window count:

{ "op": "command", "id": "request-1", "command": "workspace-list" }

The reply's result is shaped like this:

{
    "workspaces": [
        { "id": "code", "number": 1, "name": "Code", "active": true, "windows": 2 },
        { "id": "web", "number": 2, "name": "Web", "active": false, "windows": 0 }
    ]
}

The request id correlates its reply. A configured workspace ID is assigned from its initial position and stays with that MetaWorkspace if workspaces are reordered during the session. An unconfigured workspace gets an ID such as @session-1, which lasts only for that session.

Each item from workspaces has these fields:

Field	Meaning
id	Configured ID or a generated session-only ID such as @session-1.
number	Current one-based position.
name	Display label.
active	Whether this workspace is selected.
windows	Number of eligible windows on the workspace.

The older workspaces command keeps its legacy response: its numeric id is the current one-based position, and it does not include the display name.

Switch by stable ID or current number. Send exactly one selector:

{"op":"command","id":"request-2","command":"workspace-switch","workspaceId":"code"}
{"op":"command","id":"request-3","command":"workspace-switch","workspaceNumber":2}

workspace-switch also accepts a numeric workspace selector. workspace-next and workspace-previous take no selector and wrap at the ends of the current workspace list.

Switch replies contain ok, pending, and the one-based workspace number. They also include the resolved workspace's id, number, name, active, and windows fields.

Move the focused window with workspace-move-active. It accepts the same workspaceId or workspaceNumber selector, plus an optional follow boolean. The default is false; set it to true to activate the destination after moving.

For an explicit window, use command: "window", action: "workspace", and the window ID with workspaceId or workspaceNumber. The one-based numeric workspace selector is also accepted.

Successful move replies include the resolved workspace fields, follow, the stable window window ID, and the selected workspace number, workspaceId, and workspaceNumber.

Numbers can change when dynamic workspaces are removed. Use IDs in shell integrations that need to keep addressing a configured workspace. The workspace CLI examples show equivalent terminal commands.

Only command supplies a correlation ID: match reply or error by that ID because other events can arrive first. A reply with pending: true means the action was accepted; observe later state to confirm completion.

Animations are registered in Lua with gnoblin.animation and are previewed through gnoblinctl animation. Shell clients should continue to own their surface content motion; use a matching animation = "none" layer rule to avoid applying compositor motion twice.

The bridge's layer-animation-policy operation lets a shell read the configured enter/exit policy for a namespace. See the animation guide for layer-shell lifecycle events and target selection.

capture-windows returns visible, non-minimised windows in stacking order. bufferWidth and bufferHeight follow the compositor paint box and can include decoration shadows outside the frame dimensions.

Capture IDs come from Mutter; windows snapshots use a stable sequence string. Get an action ID from windows or gnoblinctl window list before sending a window action.

Example: watch the window list

Run this Python program inside your Gnoblin session:

import json
import os
import socket

path = os.environ.get("GNOBLIN_COMPOSITOR_SOCKET") or os.path.join(
    os.environ["XDG_RUNTIME_DIR"], "gnoblin/compositor-v1.sock"
)
with socket.socket(socket.AF_UNIX, socket.SOCK_STREAM) as connection:
    connection.connect(path)
    with connection.makefile("r", encoding="utf-8") as messages:
        print("Greeting:", json.loads(messages.readline()))
        connection.sendall(b'{"op":"windows"}\n')
        for line in messages:
            event = json.loads(line)
            if event.get("event") == "windows":
                print(event["windows"])

It prints the current list and subsequent snapshots as windows change. Stop it with Ctrl+C. Each snapshot replaces the previous list; it is not a list of changes.

Temporary UI bindings

Put persistent command shortcuts, including media keys, in the Lua config. A shell can use bind while it runs an interactive UI such as a switcher. Bridge bindings belong to that connection and disappear when it disconnects.

• trigger is "press" by default or "release" to wait until the accelerator's main key is released.
• Accelerator chords can include Alt, Control, Shift or Super. A held session supports Alt, Control or Super; Shift is not a valid hold value.
• Bare "Super" activates on release because Mutter first checks whether another key joins the chord.

{ "op": "bind", "id": "example", "accelerator": "<Alt>F8", "hold": 8, "trigger": "release" }

The server acknowledges:

{ "event": "bound", "id": "example" }

Hold value	Behavior
0	One activation
8	Hold Alt
4	Hold Control
67108864	Hold Super

The optional modal field defaults to true:

• Modal holds capture keyboard and pointer input for a popup. An Alt-held switcher can continue until Alt is released.
• modal: false leaves focus and input with the current app, while reporting modifier release. Use it to change shell state without opening an input UI.

This binding reports the <Alt>F8 activation and later Alt release while the focused application keeps receiving input:

{ "op": "bind", "id": "cycle-mode", "accelerator": "<Alt>F8", "hold": 8, "modal": false }

Events sent during a binding session are:

Event	Fields	Meaning
activated	id, first, session, modifiers, time	Accelerator fired.
key	key, modifiers	Key symbol and modifier mask for a captured key press.
pointer	x, y, button	Captured button press at global logical-pixel coordinates; button 1 is left.
released, cancelled	session	The modifier was released or the session ended early.

• first is true when no binding session was already active.
• session is 0 for ordinary bindings and nonzero for the built-in switcher fallback.
• modifiers is a Clutter modifier mask; time is the event timestamp in milliseconds.
• key is the Clutter key symbol.

Hide the UI when released or cancelled arrives. Sending {"op":"end"}, locking, disconnecting or reaching the ten-second timeout cancels the session.

Bare Super and buffered typing

{ "op": "bind", "id": "search", "accelerator": "Super", "hold": 0, "captureInput": true }

Requires the advertised overlay-shortcut feature. Only one bridge client can own bare Super; remove a duplicate Lua command binding first.

Super activates on release, excluding chords. With capture enabled, send:

{ "op": "shortcut-input", "name": "search", "state": "prepared" }
{ "op": "shortcut-input", "name": "search", "state": "ready" }

Use these states in order for an overlay that accepts typing:

State	Send it when	Effect
prepared	The overlay exists and its text field has focus.	Releases the compositor grab; input stays buffered.
ready	Its Wayland window is active and can receive keyboard input.	Replays buffered keys to the focused client in order.
closed	The overlay closes or stops accepting input.	Cancels pending handoff and clears the ready state.

The buffer expires after three seconds if the handoff never becomes ready. Do not send these states while the session is locked. Bingux uses this handoff for its search overlay; another shell can send the same operations. The binding ID is the handoff name.

Windows and controls

Request	Result
{"op":"windows"}	Subscribe to complete snapshots
{"op":"activate","window":"123"}	End this client's grab and focus a window
{"op":"status"}	Registered IDs and active session
{"op":"end"}	Cancel this client's input session
{"op":"clear"}	Remove this client's bindings and session

windows records include the CLI fields plus workspace, workspaceId, workspaceNumber, monitorIndex, maximized, fullscreen, and geometry. Their IDs are stable strings for the window's session lifetime.

Skip-taskbar and override-redirect windows are excluded. The client chooses grouping and ordering. Stale IDs return an error. parent links a transient dialog to its parent; lastUserTime is a recency hint.

A subscription with no open windows produces:

{ "event": "windows", "windows": [] }

When windows exist, the array uses the window record example. See CLI development for a complete request, successful reply and error reply.

Previews

{ "op": "preview", "window": "123", "width": 224, "height": 126 }

The response contains a PNG data URI in source, dimensions and window ID. On failure it returns an empty source and a message; retain the last valid image.

Maximum size: 480 × 320, preserving aspect ratio. One capture may be pending per client. No continuous stream is started; clients choose update frequency.

Capture is unavailable while locked. Readback runs at low priority, PNG encoding uses a worker, and minimised windows use their retained buffer.

Bingux text-entry integration

Text entry is provided by a Bingux-owned integration. Bingux installs a Gnoblin script that registers the namespaced bingux.input-anchor and bingux.type-text operations. Other shells can omit the integration script and implement their own text-entry behavior.

{"op":"bingux.input-anchor"} returns x, y, pid, window, frame and caret. Coordinates are logical desktop pixels. Caret may be null; it clears on focus changes and lock, and adjusts when the window moves.

{"op":"bingux.type-text","window":"123","text":"…"} accepts up to 64 UTF-16 units, without control characters. The target must be focused and unlocked, with Control, Alt and Super released.

Hide the picker and restore the target before sending. A typed reply acknowledges delivery, not proof that the app consumed the text.

For XWayland, a GTK helper temporarily offers the text and sends Ctrl+V. It preserves clipboard formats and restores them after 600 ms unless a new copy takes priority. Clipboard managers may record the temporary text.

Clipboard preparation is limited to 64 formats, 64 MiB and three seconds. Failed preparation leaves it unchanged. Native Wayland text input does not use the clipboard.

On XWayland, Bingux uses its bingux-clipboard-paste helper, which needs Python, PyGObject and GTK 3. Native Wayland text input does not use the helper. The helper and GJS integration are shipped by Bingux. The integration script is loaded from the XDG script search path; see writing scripts.

Recording and camera activity

{"op":"privacy"} subscribes to screenSharing, recording, recordingCount, recordingElapsed, cameraInUse and locationCaptures.

Location captures list authorised GeoClue desktop IDs. Elapsed time is whole seconds; clients can advance it between updates.

stop-sharing stops non-recording remote sessions. stop-recording stops recording sessions. An encoder owner should use its normal finalisation path to save output. These requests do not grant access.

Coordinate shell processes

ui-session shares advisory state and owner-directed commands between UI processes. Names match ^[a-z][a-z0-9-]{0,63}$; one client owns each name.

Action	Fields	Event
watch	None	ui-state for each owner and later changes
state	name, state object	Publishes ui-state
command	name, command	Sends ui-command to the owner

watch immediately sends each current owner state, then sends updates. A state request claims or updates a name and broadcasts its object to watchers. A second client cannot claim that name. An owner disconnect removes it and broadcasts state: null; commands are not queued for a later owner.

One client watches; another owns search and publishes its state. A watcher can then send a command to that owner. Each request goes on the named client's own bridge connection:

Client	Request
Watcher	{"op":"ui-session","action":"watch"}
Owner	{"op":"ui-session","action":"state","name":"search","state":{"visible":true}}
Watcher	{"op":"ui-session","action":"command","name":"search","command":{"action":"close"}}

The owner defines the command object's schema. Gnoblin forwards it to the current owner as ui-command; if there is no owner, the command is ignored. State is also owner-defined except for these optional stacking fields:

Field	Effect
visible	true requests the surface and its companions.
surface	Layer-shell namespace of the owning surface.
companions	Companion layer-shell namespaces; Gnoblin considers at most the first 16 string values.
revealCompanions	true requests companions even when visible is false.
companionsAbove	true places companions above the owning surface; otherwise they go below it.

The owner must provide a string surface and an array companions for the stacking request to apply. Bingux uses this to coordinate separate panels; other shells can choose their own state and command objects.

Operation	Fields	Limit or effect
blur-region	namespace, monitor origin screen: [x,y], local region: [x,y,width,height] or null	Up to 64 per client; requires a matching blur window rule; cleared on disconnect. See effect rendering.
layer-animation-policy	namespace	Returns enter, exit, windowShadow; namespace at most 128 characters

Field	Shape and accepted values	Meaning
screen	[x, y]; finite coordinates from −65,536 to 65,536	Monitor origin in desktop coordinates.
region	null or [x, y, width, height]; finite values from −65,536 to 65,536; size ≥ 0	Local rectangle; null clears the region.

Gnoblin matches the namespace and monitor origin for layer surfaces from the requesting process. A matching blur window rule is still required.

For drag layouts, subscribe with window-drag, offer hit and target rectangles using snap-offer, and apply a keyboard-chosen rectangle with snap-window. The snapping guide gives the request shapes and work-area checks.

Limits and disconnects

The socket directory is private to the user. Limits: 32 clients, 32 bindings per client, 64 queued records and 4 MiB queued output per connection. An input buffer over 16 KiB or malformed JSON closes the connection. A slow reader can also be disconnected when its output queue fills.

Invalid requests return errors. Malformed JSON or excessive input disconnects the client. Disconnect releases its bindings and other resources.
